Sterile flange

application

This aseptic method is a sterile installation flange for various devices installed on the tank, such as temperature sensors, liquid level sensors, and clamp connected sampling valves. It has excellent CIP/SIP (in place cleaning/in place sterilization) performance and can quickly install equipment to the top, bottom, and sides of the tank.

Can achieve safe and fast installation of equipment. The distance from the fixed surface is basically equal to the distance from the contact surface. Condensate or other impurities in the installation groove can be removed from the drainage hole, maintaining the cleanliness of the installation groove and avoiding corrosion or microbial growth of the flange base. Widely used in industries such as food, beverages, electronics, semiconductors, biopharmaceuticals, etc.

technical parameter

◆ Specification: 1/2"~ 4" DN10~DN100

Connection method: welding

◆ Part in contact with materials: SS304/SS316L

◆ Internal surface contact product: Ra ≤ 0.8 μ M
